VD10- Smartlin™ 4 Channel Vacuum Display And Control Unit

VD10- Smartlin 4 Channel Vacuum Display And Control Unit
VD10- Smartlin 4 Channel Vacuum Display And Control Unit

Absolute Pressure 1000 mbar to 1 x 10-9 mbar (=hPa), 750 Torr to 1 x 10-9 Torr

VD10 vacuum display and control unit is suitalbe for up to four Smartline transmitters (VSP62, VSM72, VSH82). It is used as intelligent control unit for applications in apparatus and plant engineering or special equipment construction.

Benefits

  • Large graphic LCD display with background illumination, pressure display in mbar, Torr, hPa
  • Simultaneous control of up to 4 measuring channels, pressure display in mbar, Torr, hPa
  • Easy to use, menu-driven operator instructions
  • 8 dry relay switching points
  • 2 programmable function keys
  • Interfaces CAN, Ethernet, Profibus on request
  • USB interface for process documentation
  • VacuGraph software: Documentation and evaluation of vacuum processes, remote control

Typical applications

  • Industrial plant engineering
  • Process automation
  • Coating plants
  • Vacuum furnaces
  • Apparatus engineering, e. g. process control and documentation for quality assurance
  • Special equipment construction
Enquire Now
Product Specifications:
  • Display LCD graphic display, background illuminated, 57 x 35 mm, floating point: 2 – 4 digits, exponential, 2 digits mantissa, 1 digit exponent
  • Display Refresh Rate 2 Hz (0.5 s)
  • Sample Rate 5 Hz (200 ms) per channel (RS485-serial interface, digital)
  • 30 Hz (33 ms) per channel (0 – 10 V input, analog)
  • Power Supply 95 – 265 VAC, 50/60 Hz
  • Power Consumption Max. 45 W incl. transducer
  • Fuse 2.0 A / T
  • Operating Temperature +5…+40C
  • Storage Temperature -20…+60C
  • Measuring Inputs 1 x RS485, channel 1 to 4, SubD, 15-pole, male, for VSM72, VSH82
  • 2 x 0 – 10 V, channel 1 to 2, Amphenol C91E, 6-pole, female, for VSP62
  • Control Outputs 8 x relay, normally open contact, SP free assignable,
  • Phoenix strip terminal 16-pole,
  • lifetime > 1.000.000 cycles,
  • 3 A, 250 VAC, 2 A 40 VDC
  • Serial Interface
  • Mini-USB, type B, 5-pole, female, Virtual Com Port protocol
  • Protection Class IP20
  • Weight 1100 g
