VD9 – Smartline 1 Channel Vacuum Display And Control Unit

Product Specifications:

Suitable Vacuum Transducers VCC200MA4, VSC43MA4, VSC43MV, VSP63MA4, VSP63MV, VSP63MVCF VSM72MV, VSM72MVCF, VSH82MV, VSH82MVCF
Display Alphanumeric LCD display, background illumination,
4 digits, 45 x 20 mm, floating point: 2 – 4 digits
Exponential, 2 digits mantissa, 1st. exponent
Display Refresh Rate 2 Hz (0,5 s)
Sample Rate 20 Hz (50 ms)
Power Supply 90 – 265 VAC, 50/60 Hz
Power Consumption Max. 15 W incl. transducer
Fuse 0.8 A/T
Operating Temperature +5C…+50C
Storage Temperature -20C…+60C
Measuring Inputs 2 x 4 – 20 mA, SubD, 9pole, female, for VCC200MA4, VSC43MA4, VSP63MA4
1 x 0 – 10 V Amphenol C91E, 6pole, female, for VSC43MV, VSP63MV, VSP63MVCF, VSM72MV, VSM72MVCF, VSH82MV, VSH82MVCF
Control Outputs 2 x relay contact, potential free change over switches,
Phoenix strip terminal 6-pole:
4 A / 250 VAC, 2 A / 45 VDC
Analog Output 0 – 10 V, 10 kOhm , jack plug, 2-pole
Serial Interface RS232, SubD, 9-pole, female
Protection Class IP20
Weight 750 g
